Concluding steps
▶
"Reassembling" on page 66
.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
12.8 Ultraslim ODD in an ultraslim ODD adapter
12.8.1 Installing the ultraslim ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Shutting down the server" on page 47
.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
The front cover only needs to be removed in order to remove
accessible drive dummy covers.
Accessible drives
394 Upgrade and Maintenance Manual TX1330 M4
