Position Logical drive
number
ServerView RAID Manager display
name
(Enclosure number: Port number)
[12] 12 Vendor Product (1:12)
[13] 13 Vendor Product (1:13)
[14] 14 Vendor Product (1:14)
[15] 15 Vendor Product (1:15)
With the 4x 2.5-inch PCIe SSD backplane
Position Logical drive
number
ServerView RAID Manager display
name
(Enclosure number: Port number)
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
7.5.2 Installing 2.5-inch HDD/SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: Tool-less
Preliminary steps
▶
If applicable, "Getting access to the component" on page 50
.
▶
Locate the correct drive bay, see "Overview of configurations" on page 209.
Hard disk drive (HDD) / solid state disk (SSD)
