Carefully pull the 4x 3.5-inch HDD extension box out of its installation bays.
▶
Close the locking bar
, see "Closing the accessible drive locking bar" on
page
91.
Installing accessible drive dummy covers
▶
Install accessible drive filler covers into empty drive bays, see "Installing
accessible drive filler covers" on page 93.
▶
Install accessible drive covers into the front cover, see "Installing accessible
drive covers" on page 96.
Concluding steps
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 126. Select the
corresponding system name.
▶
"Resuming BitLocker functionality" on page 121
7.6.6 Replacing the HDD backplane on the 4x 3.5-inch
HDD extension box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
Hard disk drive (HDD) / solid state disk (SSD)
262 Upgrade and Maintenance Manual TX1330 M4
