12.7.3 Replacing the ultraslim ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Locating the defective server" on page
45
.
▶
"Removing backup and optical disk media" on page 102.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
Removing the front cover is not required in order to replace the
ultraslim ODD in the 3.5-inch HDD extension box.
Removing the defective slimline ODD
▶
Remove the 3.5-inch HDD extension box, see "Removing the 8x 2.5-inch
HDD/SSD extension box" on page
247
.
▶
Remove the ultraslim ODD, see "Removing the ultraslim ODD from the
extension box" on page 391.
Installing the new slimline ODD
▶
Install the ultraslim ODD, see "Installing the ultraslim ODD into the 3.5-inch
HDD extension box" on page 386.
▶
Install the 3.5-inch HDD extension box, see "Installing the 4x 3.5-inch HDD
extension box" on page 256.
Accessible drives
TX1330 M4 Upgrade and Maintenance Manual 393
