Redundant system fan module
Figure 171: Redundant system fan module
1 Air duct
2 System fan 1, 120 x 38 mm
3
Breakouts
4 System fan 2, 120 x 38 mm
8.3 Replacing the system fan
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
Fans
TX1330 M4 Upgrade and Maintenance Manual 279
