12.3 Installing accessible drives
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Slotted screw driver (for bending in or out accessible drive
mounting brackets)
– Phillips PH2 / (+) No. 2 screw driver (for installing mounting
brackets)
Preliminary steps
▶
"Shutting down the server" on page 47
.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
The front cover only needs to be removed in order to remove accessible
drive dummy covers.
Removing accessible drive dummy covers
▶
Remove accessible drive filler covers from the required bays, see
"Accessible drive filler covers" on page 92.
▶
Remove accessible drive covers, see "Accessible drive covers" on page
95.
Installing mounting brackets to RDX backup drives
This section is not applied for Japan.
Backup drive mounting brackets are contained in mounting kit S26361-F3753-
E1 (to be ordered separately with the backup drive).
No new mounting brackets are available when replacing a backup drive
during service.
▶
If applicable, remove existing mounting brackets from the backup drive.
Accessible drives
364 Upgrade and Maintenance Manual TX1330 M4
