If applicable, remove the SAS expander board holder without disconnecting
cables, see "Removing the SAS expander board holder" on page 273
.
Position the SAS expander board holder on the HDD cages to get more
space.
Preparing the FBU
Figure 204: Installing the FBU in the FBU holder
▶
At a slight angle, fit the FBU under the right retaining bracket of the holder
.
▶
Push in the FBU until it locks in place.
▶
Ensure that the FBU is properly seated in the FBU holder
.
Expansion cards and backup units
320 Upgrade and Maintenance Manual TX1330 M4
