Fujitsu PRIMERGY TX1330 M4

Figure 246: Disassembling the slimline ODD dummy module
▶
Disengage (1) and remove (2) the slimline ODD dummy from the slimline
ODD installation frame.
Installing the slimline ODD into the Multibay box
Figure 247: Mounting the slimline ODD in the installation frame
Accessible drives
374 Upgrade and Maintenance Manual TX1330 M4
