Fujitsu PRIMERGY TX1330 M4

14.5 iRMC microSD card 427
14.5.1 Note for embedded Lifecycle Management (eLCM) 427
14.5.2 Installing the iRMC microSD card 427
14.5.3 Removing the iRMC microSD card 429
14.5.4 Replacing the iRMC microSD card 431
14.6 M.2 SSD 432
14.6.1 Slots and bolts for M.2 SSDs 432
14.6.2 Installing an M.2 SSD 433
14.6.3 Removing an M.2 SSD 437
14.6.4 Replacing an M.2 SSD 439
14.7 Dual microSD 64GB Enterprise 440
14.7.1 Position of the Dual microSD 64GB Enterprise 440
14.7.2 Installing the Dual microSD 64GB Enterprise 441
14.7.3 Removing the Dual microSD 64GB Enterprise 443
14.7.4 Replacing the Dual microSD 64GB Enterprise 445
14.7.5 Replacing the microSD card 447
14.8 System board 449
14.8.1 Replacing the system board 449
15 Converting a floorstand model to a rack model 459
16 Cabling 475
16.1 Replacing the intrusion switch cable 475
17 Appendix A
487
17.1 Mechanical overview 487
17.1.1 Server front 487
17.1.1.1 2.5-inch HDD/SSD model 487
17.1.1.2 3.5-inch HDD model 488
17.1.2 Server rear 490
17.1.2.1 Server rear with standard PSU 490
