In the following sections the figures are shown for the TX1330 M4 (rack
model).
The only difference to a TX1330 M4 (floorstand model) in horizontal
position: the accessible drive cage is turned around clockwise for
90 degrees.
Figure 84: Rack model versus floorstand model with drive cage turned
Backplane overview
Hard disk drive (HDD) / solid state disk (SSD)
TX1330 M4 Upgrade and Maintenance Manual 171
