Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
No steps needed.
Installing a 3.5-inch HDD in a 3.5-inch installation frame
Figure 95: Installing the 3.5-inch HDD in the 3.5-inch installation frame (A)
▶
Lay the 3.5-inch HDD into the 3.5-inch installation frame as shown.
Hard disk drive (HDD) / solid state disk (SSD)
TX1330 M4 Upgrade and Maintenance Manual 179
