Controller (LED F)
Status Description
off Controller okay
orange on Controller failure (PCI card installed on riser card)
Memory (LED G)
Status Description
off memory module running
orange on memory module failure
iRMC (LED H)
Status Description
off iRMC S5 inactive
orange on iRMC S5 okay
Fans (LED I)
Status Description
off system fan running
flashing green system fan failure
Standby Power (LED K)
Status Description
orange on All standby voltages ok
Appendix A
498 Upgrade and Maintenance Manual TX1330 M4
