LAN speed indicator (2)
Status Description
yellow on Data traffic at a transfer rate of 1 Gbit/s.
green on Data traffic at a transfer rate of 100 Mbit/s.
off Data traffic at a transfer rate of 10 Mbit/s.
Indication of LAN connection supporting Energy Efficient Ethernet (EEE
mode)
To configure the EEE mode, it is necessary that the on board LAN or an add in
LAN card supports this mode and the connected switch supports this mode as
well.
Pos.
Indicator Status Description
1 LAN link/
transfer
indicator
short flashing
green 3x,
then off
A LAN connection has been established
(1
Gbit or 100 Mbit) and EEE mode is
active
2 LAN
speed
indicator
short flashing
yellow 1x,
then
2 seconds off
green off
Data traffic at a transfer rate of 1 Gbit/s.
short flashing
green 1x,
then
2 seconds off
yellow off
Data traffic at a transfer rate of 100 Mbit/s
Table 5: LAN indicators if EEE mode is active
Appendix A
510 Upgrade and Maintenance Manual TX1330 M4
