Figure 13: Unlocking the server
▶
Insert the key into the lock on the server front.
▶
T
urn the key clockwise to unlock the front and side covers (1).
▶
Remove the key from the server front (2) and set aside for later use.
Basic hardware procedures
TX1330 M4 Upgrade and Maintenance Manual 59
