Fujitsu PRIMERGY TX1330 M4

Rack model
Figure 46: Opening the accessible drive locking bar (rack model)
▶
Pull up the locking latch to disengage the accessible drive locking bar (1).
▶
Fold up the accessible drive locking bar (2).
Basic hardware procedures
90 Upgrade and Maintenance Manual TX1330 M4
