GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
3-26 Section 3-13 - Loading Application Software
3-13-1Loading Applications Software (cont’d)
7.) When the process has completed, the window will turn dark red and you will see the following
message in Figure 3-18.
8.) When it completes loading the system will reboot.
If possible while the system is rebooting remove the CD from the drive. If the CD is remove the system
will automatically reboot into the applications software.
If you didn’t remove the CD, don’t worry you will get a dialog box as in Figure 3-19.
9.) REMOVE the Applications CD
10.)From the Start Applications dialog box, select START
.
11.)Select CANCEL
.
Figure 3-18 Software Load Complete
Figure 3-19 Start Software
