Program description - Stick mode | Winged models
Column “St”
The four digital trim switch-keys shift the neutral point
of the respective stick in the given direction by one
adjustable increment, as set here, for each “click”. This
is where the increment size (step) can be adjusted for
a given direction, whereby maximum trim travel, inde-
pendent of the selected number of trim steps, is always
about ±30 % of control travel.
After selecting the “St” column ((trim) steps) and the
desired trim control with the selection keys of the
left or right four-way button, the corresponding entry
field will be framed, for example:
Tr
+
4
4
4
0.0s
0.0s
0.0s
4
0.0s
0.0s
0.0s
0.0s
0.0s
GL
GL
PH
PH
St
Ch.1
Aile
Elev
time
Rudd
Briefly tap the centre SET key of the right four-way
button. The current setting will be displayed in inverse
video. Now select the desired value, between 1 and
10, with the selection keys of the right four-way button,
for example:
Tr
+
4
4
0.0s
0.0s
0.0s
4
0.0s
0.0s
0.0s
0.0s
0.0s
GL
GL
PH
PH
St
8
Ch.1
Aile
Elev
time
Rudd
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will reset any change made
to the active field back to “4”.
Column “- time +”
The rate of control signal change with respect to the
speed of stick motion can be influenced by the entries
made in the “– time +” column. Each stick movement
direction, i. e. stick control channels 1 through 4, can
be set individually. This means that respective servos
will then follow rapid control position changes only
at an accordingly delayed rate. This time delay has a
direct effect on the control function and therefore also
any servos controlled by this function.
The time can be programmed symmetrically for both
sides or separate for each control direction. This set-
ting has a programmable range of 0 s to 9.9 s. In the
case of side-separate settings, the stick is to be moved
to the respective side so that the inverse video field will
switch between sides to the one for which the change
is to be made – for example, even to ensure gentle rev-
up of the propulsion motor despite a (too) fast motion
of the C1 stick.
Tr
+
4
4
4
0.0s
0.0s
4
0.0s
0.0s
0.0s
0.0s
0.0s
GL
GL
PH
PH
St
1.1s
Ch.1
Aile
Elev
time
Rudd
On the other hand, for reasons of safety, the motor cut-
off should always be “immediate”.
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will reset any change made
to the active field back to “0.0 s”.
