36
Transmitter description - Hidden mode
The mc-16 HoTT and mc-20 HoTT transmitter’s
»HIDDEN MODE« menu can be called up from almost
any menu position by touching and holding the
selection keys of the left four-way button and the SET
key of the right four-way button for at least 3 seconds.
This will produce the display shown below.
HIDDEN MODE
VOICE
STICK CALI.
FIRMWARE UPDATE
BLUETOOTH INIT.
VOICE
As mentioned in section “Headsets” on page 25, the
transmitter’s acoustic signals as well as those signals
and announcements associated with the »Telemetry«
menu can be output by way of the headset connector.
These announcements are made in German language
by default. These announcements are summarized in
a voice packet which is stored in a transmitter-internal
memory but they can be replaced by a voice packet of
a different language at any time.
At the time of this manual’s revision, the standard SD
card delivered with the set includes the following lan-
guages:
• Dutch
• English
• French
• German
• Italian
• Spanish
The given active language packet can be swapped out
either with the PC program available as a download
from the transmitter’s web page at www.graupner.de or
with the SD card, as described below.
HIDDEN MODE
Language selection, Firmware update, Stick calibration etc.
If not already done, insert the SD card or SDHC card
into the transmitter as described on page 26. Once
the memory card is inserted in the transmitter, switch
the transmitter on with RF switched off.
Please select
RF on/off?
ON OFF
Now move to the »HIDDEN MDE« menu as described
earlier in this section:
Language change
Use the selection keys of the left or right four-way but-
ton to select the line “VOICE” line:
HIDDEN MODE
VOICE
STICK CALI.
FIRMWARE UPDATE
BLUETOOTH INIT.
Use the centre SET key of the right four-way button to
switch to the selection page for the “VOICE” line:
FILE LIST
VOICE2_FRANCE.VDF
VOICE2_GERMAN.VDF
VOICE2_ITALIANO.VDF
VOICE2_SPAIN.VDF
VOICE2_ENGLISH.VDF
VOICE2_DUTCH.VDF
Now use the keys of the left or right four-way but-
ton to choose the desired language, for example:
FILE LIST
VOICE2_FRANCE.VDF
VOICE2_SPAIN.VDF
VOICE2_GERMAN.VDF
VOICE2_ITALIANO.VDF
VOICE2_DUTCH.VDF
VOICE2_ENGLISH.VDF
Confi rm the choice with another tap on the centre SET
key of the right four-way button. The selected language
packet will be loaded into the transmitter’s memory:
22/100%
I
HIDDEN MODE
VOICE
STICK CALI.
FIRMWARE UPDATE
BLUETOOTH INIT.
The loading process is fi nished as soon as the progress
bar at the lower edge of the display disappears:
HIDDEN MODE
VOICE
STICK CALI.
FIRMWARE UPDATE
BLUETOOTH INIT.
When this process is fi nished, switch off the transmitter.
All settings stored in the transmitter remain intact after
a change of language has been made.
Notes:
•
If the warning …
RF
must be
OFF
OK
