Program description - Base setup models | Winged models
Channel assignment on second receiver
As already mentioned, the “Receiver channel map-
ping” menu point can be used to map (re-distribute)
the transmitter’s control channels in any way amongst
a maximum of two receivers; these are the eight con-
trol channels of the
mc-16 HoTT transmitter, and the
twelve channels of the mc-20 HoTT transmitter. In
this case the numbering of the outputs (servo sockets)
and the maximum number of lines (outputs) available
reflects the maximum number of servos which can be
connected to the receiver in question.
Receiver CH – BIND2
In Ch
1
In Ch
2
In Ch
3
In Ch 4
8
8
8
8
Out Ch
Out Ch
Out Ch
Out Ch
Receiver CH – BIND2
In Ch
In Ch
In Ch
In Ch
12
12
12
12
1
2
3
4
Out Ch
Out Ch
Out Ch
Out Ch
Note:
The upper screen-shot above shows the
screen of the mc-16 HoTT eight-channel
transmitter; the lower one the screen of the
mc-20 HoTT twelve-channel transmitter.
After selection of the desired output with the selection
keys of the left or right four-way button, the respec-
tive input field will be framed. Tap the centre SET key
of the right four-way button. The current setting will
be displayed in inverse video. Now select the desired
input channel with the selection keys of the right four-
way button. For example, suitable to the above rudder
example:
Receiver CH – BIND2
In Ch
In Ch
In Ch
In Ch
4
4
4
1
2
3
4
Out Ch
Out Ch
Out Ch
Out Ch
4
Note:
The maximum number of lines (outputs)
available reects the maximum number of
servos which can be connected to the
receiver in question.
RF transmit
This menu line provides an option for manually switch-
ing the transmitter’s RF transmission on and off to
specific models while the transmitter is in operation.
For example, to save power while a model is being
programmed.
If this line option was set to OFF, it will be
canceled (i. e. set to ON) the next time the
transmitter is switched on.
If necessary, use the selection keys of the left or
right four-way button to move into the “RF transmit“
line then activate the option with a brief tap on the cen-
tre SET button of the right four-way button:
1
bind
bind
SEL
Rcv Ch Map R12
R08
HoTT
Stick mode
module
Base setup model
RF transmit ON
The right selection keys can now be used to choose
between OFF and ON. Another tap on the centre SET
key of the right four-way button will conclude the entry.
Range test
Note:
This menu line is suppressed if you select
“EXT.” or “SP.” in the “Module” line.
The built-in range test reduces transmission power to
an extent that a functional test can be carried out even
within a distance of less than 100 m.
Perform a range test on the Graupner HoTT system
according to the following instructions. If necessary,
have someone assist you in carrying out the range test.
1. Preferably, the receiver already bound to the trans-
mitter should be installed into the model in its in-
tended position.
2. Switch remote control on and wait for the green
LED to light up on the receiver/s. Now servo move-
ments can be observed.
3. Place the model on a level surface (pavement, low-
cut grass or bare ground) such that receiver anten-
nas are at least 15 cm above ground level. It may
be necessary to put something under the model to
raise it up enough for this.
4. Hold the transmitter at hip level and at some dis-
tance from one’s body.
5. If necessary, use the selection keys of the left
or right four-way button to reach the “RF range test”
line in the menu then start range test mode with a
tap on the centre SET key of the right four-way but-
ton:
