228
Program description - Pro trim | Winged models
Pro trim
Flaps and aileron trimming
This option is available on both transmit-
ter types.
The transmitters
mc-16 HoTT and mc-
20 HoTT has an integrated software func-
tion for direct trimming of all flaps and ailerons.
This feature, named »Pro trim« because of its func-
tional similarity to the Profi-Trim module for the mc-24
but only available on that transmitter as a re trofit op-
tion. Select this feature from the multi-function menu
with the selection keys of the left or right four-way
button …
Tx. output swap
Telemetry
Fail-safe adjust
Profi trim
Trim memory
Teacher / pupil
… then open this menu option with a brief tap on the
centre SET key of the right four-way button.
Profi trim
AI
AI
FL
FL
TR
CTL
ON/OFF
OFF OFF OFF OFF
–––
–––
–––
–––
–––
SET SET SET SET
Programming procedure
Programming is done in three steps:
First of all, in the “TR” line it will be established just
which flap pair is to be trimmed as “AI” and/or “FL”.
The “CTL” line specifies the control channel over which
the given trim function is to be performed and, finally,
a switch is defined in the “ON/OFF” line by which this
profi-trim function can be switched on or off globally.
To set the desired option, move the marker frame onto
the desired line or column with the selection keys of the
left or right four-way button then briefly tap the centre
SET key of the right four-way button. Select the de-
sired entry in the field now displayed in inverse video
with the selection keys on the left or right four-way but-
ton or move the desired transmitter control. Conclude
the procedure with a tap on the ESC key.
TR
Notes:
•
Please note that, depending on the num-
ber of aileron and ap servos specied in
the »Model type« menu, page 99,
some settings cannot be used. For example, with
only 1 aileron and/or 1 ap servo there is no ailer-
on ap activation possible, and the opposite is
also true. Since this is the case, a number of set-
tings in various columns remain ineffective.
• Pay attention to potential double-assignments
when making trim control choices.
The trim functions which can be activated (ON) or
deactivated (OFF) on the first line of this menu, either
individually or in any combination, make pre-flight cor-
rections to aileron and flap settings quick and easy,
without the complexity of having to call up individual
setting options.
Individually, these are functions for …
• Trim of the aileron function for aileron (“AI”)
