257
Program description - Multichannel
Further information can be found in Internet at
www.graupner.de. Use the search mask by entering
the respective No. Alternatively, contact or visit your
local dealer.
Programming procedure
Use the selection keys on the left or right four-way but-
ton to scroll to the menu option »Multichannel« menu
option in the multi-function menu:
Profi trim
Trim memory
Telemetry
Channel sequence
Multichannel
Ring limiter
… then open this menu option with a brief tap on the
centre SET key of the right four-way button.
Here, in the second column from the left, each of the
two multi-channel functions can be activated (“ACT”) or
deactivated (“OFF”) as desired and in the third co lumn
the given function can be assigned to one of the trans-
mitter channels, 5CH through 8CH, in a list:
MC1
MC2
Multichannel
SET
SEL
OFF
OFF
MUL4CH
MUL4CH
5CH
SEL
6CH
Note:
When a changeover is made to the »Servo
display« or if »Servo adjustment« is used to
select the “- travel +” or “- lim +” columns for
these previously set channels, their respective cells
will ash to indicate that these channels have been
activated in the »Multichannel« menu. The preset
values of 100 % or 150 % should not be changed.
Prior to channel selection, please observe the
following notices:
1. Switch to the “SETTINGS/DISPLAYS” line of the
»Telemetry« menu and tap on the centre SET key
of the right four-way button:
• on the “RX SERVO” page, select the “20 ms”
setting in the last line “PERIOD”, see page 240.
• On the “RX SERVO TEST” display page, select
the “SAME” option for the last line “CH OUT
TYPE”, see page 246.
2. The control channel used may not be used as an in-
put nor as an output channel for any mixer! For ex-
ample, if 5CH is selected, be sure that the “Aile/
flaps” line of the »Model type« menu is preset to
“1AIL” or that the “Swashplate type” line of the
»Helicopter type« menu is preset to “1 servo”.
3. The channel settings intended for NAUTIC con-
trol channel purposes in the »Control adjust« and
»Servo adjustment« menus are to be left as they
are or reset back to their original settings. Do not
assign any transmitter control or switch to the re-
spective input either. Also be sure that the servo’s
direction of rotation is not reversed. Leave the servo
middle at 0 %.
In the next column to the right, make a separate
channel count specification for each of the two multi-
channels; “MUL4CH” for the NAUTIC-Multi-Prop mini
decoder, No. 4142.N or “MUL8CH” for the NAUTIC-
Expert switching module, No. 4159, for example:
Multichannel
Channel multiplier for special functions
This option is available on both transmit-
ter types.
The transmitter
mc-16 HoTT and mc-
20 HoTT has an integrated multi-function
channel built into the transmitter’s software. This faci lity
permits up to two control channels to be used for up
to four or eight special functions. Every available switch
(including the so-called expansion switches, see page
60) or transmitter control can be assigned on the
transmitter side.
On the receiver side, the following modules are availa-
ble as accessories, whereby at one time a maximum of
two modules can be operated via the »Multi-channel«
menu.
NAUTIC-Expert, switching module, No. 4159
The NAUTIC-Expert switching module expands a
servo’s functionality to 16 switched functions. By ap-
propriately wiring the connecting cable, loads can
either be operated from a common power supply or
also separately by multiple power sources.
NAUTIC-Multi-Prop mini-decoder No. 4142.N
The 1/4 C-NAUTIC-Multi-Prop mini-decoder expands a
proportional function to four proportional functions.
Light module No. 2381
A module for switching the light signals of rail, road and
airborne vehicles with true authenticity.
Sound switch for vehicle models No. 2382.F
start, stop and supplementary sounds as well as typi-
cal vehicle signals
Sound switch for ship models No. 2382.S
start, stop and supplementary sounds as well as typi-
cal ship signals.
mc
16 20
