GRAUPNER mc-16 Programming Manual

17
Remote control set description
mc-16 HoTT and mc-20 HoTT transmitter
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Transmission power 100mW EIRP
Control functions
mc-16 HoTT:
8 functions, 4 of these can be
trimmed, can be expanded to
12 functions at extra cost
mc-20 HoTT:
12 functions, 4 of these can be
trimmed
Temperature range -10 … +55 °C
Antenna Integral patch aerial inside
case
Operating voltage 3.2 … 4.8 V
Current draw about 400 mA
Range up to about 4 000 m
Dimensions about 235 x 228 x 66 mm
(without hand rests)
Weight about 1200 g with transmitter
battery, without accessorys
GR-12L HoTT receiver (No. S1012)
Operating voltage 3.6 … 8.4 V*
Current draw about 70 mA
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Antenna 1 diversity antenna, about
145 mm long, about 115 mm
of this length encapsulated
and about 30 mm active
Plug-in servos 6
Sensor sockets 1 (in place of servo 5)
Temperature range -10 … +55 °C
Dimensions about 36 x 21 x 10 mm
Weight about 7 g
GR-16 HoTT receiver (No. 33508)
Operating voltage 3.6 … 8.4 V*
Current draw about 70 mA
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Antenna 2 diversity antennas, about
145 mm long, about 115 mm
of this length encapsulated
and about 30 mm active
Plug-in servos 8
Sensor sockets 1
Temperature range -10 … +55 °C
Dimensions about 46 x 21 x 14 mm
Weight about 12 g
GR-24 HoTT receiver (No. 33512)
Operating voltage 3.6 … 8.4 V*
Current draw about 70 mA
Frequency band 2.4 … 2.4835 GHz
Modulation FHSS
Antenna 2 diversity antennas, about
145 mm long, about 115 mm
of this length encapsulated
and about 30 mm active
Plug-in servos 12
Sensor sockets 1
Temperature range -10 … +55 °C
Dimensions about 46 x 31 x 14 mm
Weight about 16 g
Technical data
* The specication for permissible operating voltage
range applies only to the receiver. Please note in this
context that receiver input voltage is applied without
regulation to connected servos but the voltage range for most
connectable servos (speed controls, gyros, etc.) is only 4.8 to
6 V
