98
Program description - Model type | Winged models
This option is available on both transmit-
ter types.
Use the selection keys on the left or
right four-way button to select the »Model
type« option in the multi-function menu:
Suppress models
Base setup model
Servo adjustment
Control adjust
Model type
Stick mode.
Open this menu option with a tap on the centre SET
key of the four-way button pad.
This “Model type” menu is used to establish the type of
model to be programmed. This also activates all char-
acteristic mixers, coupling functions, etc. in pre paration
for subsequent programming of the specified model
type.
Motor at C1
When you open the »Model type« menu, the input field
of the “Motor at C1” line is generally already framed
(selected). If this is not the case, use the Select buttons
of the left or right-hand four-way button to move
to the “Motor at C1” line:
Tail type
Motor at C1
Normal
None
Aile/flaps
1AIL
Model type
Brake Off In 1+100%
SEL
Briefly tap the centre SET key of the right four-way
button: The current setting will be displayed in inverse
video. Now use the selection keys of the right four-way
button to select from among the following four options:
• “none“
For operation of a model without a propulsion.
The warning “Throttle too high”, see page 35, is
deactivated and the “Brake settings” sub-menu of
the »Wing mixers«, beginning page 180, is availa-
ble without any restrictions.
• “back”
The idle position for the throttle/brake flaps stick
(C1) is to the rear, i. e. toward the pilot.
The warning “Throttle too high”, see page 35, as
well as the “cut off” option in the »Basic settings,
model« menu, see page 85, are activated and
the “Brake settings” sub-menu of the »Wing mix-
ers« menu, beginning page 180, will be available if
the entry in the “Motor” column of the »Phase set-
tings« menu, page 148, for the currently active
flight phase is “none”.
• “front”
The idle position for the throttle/brake flaps control
stick (C1) is at the front, i. e. away from the pilot.
The warning “Throttle too high”, see page 35, as
well as the “cut off” option in the »Basic settings,
model« menu, see page 85, are activated and
the “Brake settings” sub-menu of the »Wing mix-
ers« menu, beginning page 180, will be available if
the entry in the “Motor” column of the »Phase set-
tings« menu, page 148, for the currently active
flight phase is “none”.
Notes:
•
Be sure to pay attention during the pro-
gramming procedures that motors do
not start up unintentionally. Disconnect
the fuel supply or battery terminals to motors
before programming.
• C1 trimming will operate according to the choice
made between “normal” or only “back” or “front”,
that is, either over the control’s entire travel path
or only in the respective idle direction.
Model type
Establishing winged aircraft model type
mc
16 20
the transmitter is switched on.
In contrast, the “slot time” – see page 159 – is always
reset to the starting value when the transmitter is
switched on.
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will reset the display to “yes”.
