ADVANCED MEASUREMENT
89
Watt result
appears
Shows measured
dBW (Watt) value
F2 (MathDisp) key
to show STAT &
Math
Press the F2 (MathDisp) key to show the
Math Display menu as the figure below
shown. Proceed to the F2 (STAT) or F3
(Math) display in accord with the
following chapters.
Show STAT result
Background
The STAT page in MathDisp allows you to
make statistical calculations for several
measurements including Minimum,
Maximum, Average Peak-Peak, Standard
Deviation and Count.
Operation
Press the F2 (STAT) key to show
the statistical data immediately as the figure
below.
View Data
+00.00000 dBW
Indicates the latest dBW value
Minimum
Indicates the minimum data
value
Maximum
Indicates the maximum data
value
