OPERATION
51
4. Press the HI/LO SET soft-key and
then use the scroll wheel to set the
LO SET limit.
ACW (LO)
DCW (LO)
IR (LO)
OFF, 001μA~32.99mA
OFF, 001μA~10.99mA
000.1MΩ~50.00GΩ
Set LO SET limit
5. Press the SAVE soft-key to complete.
Note
*Please note that the resolution of the measured
value depends on the resolution of HI SET setting.
Note
The LO SET setting is limited by the HI SET
setting. The LO SET limit cannot be greater than
the HI SET limit.
