Chapter 5 Front Panel Interface ProView 7000 Front Panel Operation
© 2011 Harmonic Inc. 146 ProView 7000 v.2.4, Rev. A
5.1.2.3 Edit Value Screen
The Edit Screen is used for editing parameter values. The parameter value is written using the
alphanumeric keypad. The parameter value can be a number or a string.
Use the Left and Right arrow keys to select a digit and the Up and Down arrow keys to change
the value of the parameter. Press
Enter to confirm the change or Esc to escape and return to
the original value.
5.1.2.4 Select Value Screen
The Select Value screen displays a list of option values and enables selecting one of them
(
ƒ = currently active, ‚ = currently inactive):
Use the Up and Down arrow keys to move between the options and press Enter to select the
required option. After pressing Enter, the selected option is activated.
Universal
10.750000 [GHz]
<10.700000 - 11.900000>
Modulation Standard
ƒ DVB-S
‚ DVB-S2
