Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 167 ProView 7000 v.2.4, Rev. A
❑ SAT 3
❑ SAT 4
❑ ASI 1
❑ ASI 2
❑ ASI 3
❑ ASI 4
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
❑ None
■ Input Type – Use this menu to select the input type MPEG or DVB.
■ Output Selection – Use this menu to individually enable or disable the following physical
outputs:
❑ ASI 1
❑ ASI 2
❑ Socket 1
❑ Socket 2
❑ Socket 3
❑ Socket 4
■ Descrambling – Select a program then select one of the following CAM slots:
❑ CAM 1
❑ CAM 2
❑ None
5.2.4 GbE Menu
The GbE menu has the following sub-menus:
■ Active Port – Use this menu to select the active port when the mode is set to In. The
default is port 1.
■ GbE Port 1/2 – Use these menus to configure the following:
❑ IP Configuration – Use this menu to configure the following:
• IP Address – The default is 127.127.0.X (X is the port number). Each port must have a
unique IP address.
• Subnet Mask – The default is 255.255.255.0.
• Gateway – Output mode only. The default is 127.127.0.1.
❑ MAC Address – Use this menu to view the MAC address for this port.
2. The number of RF satellite inputs depends on your hardware configuration.
