Appendix A Characteristics and Specifications Video and Audio Interfaces
© 2011 Harmonic Inc. 180 ProView 7000 v.2.4, Rev. A
Audio Decoding
■ 2 Stereo pairs audio decoding
■ Stereo down-mix
■ MPEG-1 Layer-II (Musicam)
■ Dolby Digital®
1
❑ Dolby Digital 2.0
❑ Dolby Digital 5.1 down-mix to 2.0
❑ Dolby Digital 5.1 pass through (AC-3 only)
■ Dolby E
1
/ Linear PCM Pass Through
■ AAC LC
❑ AAC LC 2.0 audio
❑ AAC LC 5.1 audio down-mix to 2.0 audio
■ HE AAC v1 and v2
❑ HE AAC 2.0 audio
❑ HE AAC v1 5.1 audio down-mix to 2.0 audio
A.7 Video and Audio Interfaces
Video outputs
■ 2 x composite video interfaces (1 broadcast and 1 monitoring)
■ 2 x SD/HD-SDI with embedded audio (mirrored)
■ 1 x analog video RGB-HD 15 pin D-connector
■ HDMI for monitoring
Audio outputs
■ 2 x analog audio stereo pairs, balanced (15 pin D-connector)
■ 2 x digital audio (AES/EBU-S/P-DIF)
■ 2 balanced digital audio interfaces (15 pin D-connector)
A.8 Control and Monitoring
■ Front panel keypad and LCD
■ Web browser interface
■ SNMP traps and alarms
■ Ethernet: RJ-45 100/1000BaseT control interface
■ Terminial: RS-232
1. Dolby, Dolby E and Dolby Digital are registered trademarks of Dolby Laboratories.
