© 2011 Harmonic Inc. 24 ProView 7000 v.2.4, Rev. A
Chapter 3
Configuration and Monitoring
The sections are:
■ Configuring the IP Parameters
■ The ProView 7000 EMS
■ How to Configure and Monitor the ProView 7000
■ Low Delay Mode
3.1 Configuring the IP Parameters
To configure the IP parameters of a ProView 7000:
1. Press Enter on the keypad.
The root menu displays.
2. Navigate Unit > Management Port > IP Configuration.
3. Set the IP Address, Subnet Mask and Default Gateway for the port.
4. After any change in the IP configuration, the Apply port changes item is added to the IP
Configuration sub-menu to allow confirmation of the port setup.
5. Select Apply port changes.
6. Select Apply Changes to apply or Drop Changes to abort the configuration.
3.2 The ProView 7000 EMS
The ProView 7000 EMS application provides a GUI for easy management the ProView 7000s.
You can manage up to 10 devices with EMS. Most EMS functions can be performed via the
front panel. You need to have an internet or LAN connection to use EMS.
3.2.1 EMS System Requirements
Minimum platform requirements for EMS:
■ P4 or equivalent processor @ 2 GHz or higher
■ 1 GB of RAM (2 GB highly recommended)
■ Windows XP, Windows Vista, or Windows 7 operating system
IP Configuration
1 IP Address
127.000.000.010
2 Subnet Mask
255.255.255.000
3 Default Gateway
000.000.000.000
