· UDP Port – The range is 0 – 65535. The default is 1000.
• Socket De-Jittering Mode – The default is Normal. The options are:
· Low – Low Delay
· Normal – Network jitter less than 50 msec.
· High – Network jitter less than 300 msec.
• Socket De-Jittering Status – Status display only.
• SSM – Options:
· Enable – You can configure one source IP address. Only packets with this source
address are processed.
· Disable – The device accepts all packets with destination IPs and ports that match
the socket regardless of their source IP.
Routing Table – Use the Routing Table menu to manage up to five routing destinations for
GbE mode In when the IP address is on a different network. The Routing Table menu
comprises 5 Entry sub-menus.
In each Entry sub-menu you can configure the following:
❑ Destination Type – The options are:
•Network
•Host
❑ IP Address
❑ Subnet Mask
❑ Default Gateway – The Default Gateway must be the same as the device management
port address.
❑ Interface – The options are:
•GbE 1
•GbE 2
5.2.5 Alarms Table Menu
The Alarm Monitoring screen displays a list of all active alarm messages raised by the
ProView
7000 device.
To display the alarm list screen:
❖ Navigate Root > Alarms Table.
Severity Alarm Time
1 Major Link down 22:58
2 Critical Voltage Error
