Chapter 3 Configuration and Monitoring How to Configure and Monitor the ProView 7000
© 2011 Harmonic Inc. 32 ProView 7000 v.2.4, Rev. A
To read the alarm messages:
1. To display the alarm list screen, navigate Root > Alarms Table.
The Alarm Monitoring screen displays a list of all active alarm messages raised by the
ProView 7000 device. The information is displayed in a tabular format, providing the
alarm severity level, the alarm brief description and the time the alarm was triggered.
2. Select an alarm from the list to display its details.
The Alarm detailed screen provides the following information:
■ The Alarm brief description
■ The Alarm severity level and the full date and time the alarm was triggered
■ A detailed description of the alarm
■ Suggested corrective action option – select this option to display suggested corrective
action
3.3.3 Configuring the ProView 7000 using EMS
The ProView 7000 has four logical multiplexes. A license is required for using more than one
multiplex. Some hardware configurations support up to four satellite RF inputs. All
ProView
7000s have 2 GbE data ports.
The EMS enables building your own decoded output stream, by selecting specific elementary
stream from a program. Drag and drop the ES icon from the input program branch onto the
Output decoding icon. The ES Decoding Properties dialog displays, allowing you to set the
relevant parameters. Do not use ESs from different programs.
TIP: Descrambling Set-Up TIP:
When setting a program or an ES for decoding, the decoder properties menu enables the user to
descramble the program and to select the CAM slot for the descrambling process.
For a detailed description of the options provided by the Decoding Channel Properties dialog see
4.5.4.7 Decoding Channel Properties.
Severity Alarm Time
1 Major Link down 22:58
2 Critical Voltage Error
Link down
Major, 12 Apr, 14:59:10
Link down on GbE Port 2.
Alarm Corrective Action
