Appendix A
Characteristics and Specifications
A.1 DVB-S/S2 RF Input Interfaces
L-Band RF input with LNB control
■ Connectors: 4 x F-type, 75 Ω
1
■ Frequency range: 950 – 2150 MHz
■ RF input level: -65 – -25 dBm
■ LNB power: 13 VDC, 18 VDC / 350 mA
A.2 Transport Stream Input Interfaces
DVB-S Input
■ Connector: 4 x RF In
1
(common connector with DVB-S2)
■ Constellation: QPSK
■ Symbol rate: 1 – 45 Msps
■ FEC: All ratios compliant with standard
DVB-S2
2
Input
■ Connector: 4 x RF In
1
(common connector with DVB-S)
■ Constellation: VCM, QPSK, 8PSK, 16APSK
3
■ Symbol rate: 1 – 45 Msps
■ FEC: All ratios compliant with standard
■ FEC Blocks: Short and normal
■ Roll off: 0.2, 0.25 and 0.35
■ Mode: CCM
■ Pilots: On and off
ASI Input
■ Connector: 4 x BNC, 75 Ω
■ Packet Length: 188 and 204 byte packets
■ TS max bit rate: 160 Mbps
1. More than one RF in with certain hardware configurations.
2. Requires a license with some hardware configurations, see Appendix C for details.
3. A license is required for 16APSK modulation. Only available with certain hardware configurations.
