Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 166 ProView 7000 v.2.4, Rev. A
Selecting any of the VBI option in the menu, opens a screen which enables the user to select
the source of the data and displays the number of the line used to carry the data:
■ AMOL – Automatic Measurement Of Line-ups information.
Source: Disabled, VBI ES
Location: Line 1: 20, Line 2: 22.
■ CC – Close Captioning information.
Source: Disabled, VBI ES, Video ES. Location: Line 1: 21
■ TVG – TV Guide information.
Source: Disabled, ES DVB.
■ WSS – Wide Screen Signaling information.
Source: Disabled, VBI ES, Video ES.
Location: Line 1: 23.
■ TTX – Teletext EBU information.
Source: Disabled, VBI ES.
■ VPS – Video Program System information.
Source: Disabled, VBI ES.
Location: Line 1: 16.
■ VITS – Vertical Interval Test Signal information.
Source: Disabled, Internal.
Location: Line 1: User Selected, Line 2: User Selected.
■ VITC – Vertical Interval Test Code information.
Source: Disabled, Internal, Video.
Location: Line 1: User Selected, Line 2: User Selected.
■ VI – Video Index information.
Source: Disabled, VBI ES.
Location: Line 1: 11.
■ M422 – Monochrome 4:2:2 information.
Source: Disabled, VBI ES.
5.2.3 Routing and Descrambling Menu
The Routing menu has from 1 to 4 multiplexes
1
, namely:
■ TS1
■ TS2
■ TS3
■ TS4
You can use any multiplex for routing.
Each multiplex menu has the following sub-menus:
■ Activation – Use this menu to enable or disable the multiplex.
■ Input Selection – Use this menu to select one of the following physical input ports:
❑ SAT 1
❑ SAT 2
2
1. A license is required for more than one multiplex.
