4.4.4 Physical Output Box
The Physical Output box of the Device Explorer tab presents a hierarchical tree-structure of
the ProView
7000 physical output ports for monitoring and configuring the features of each
element displayed in the tree.
The ProView 7000 features various types of outputs:
■ ASI output ports
■ GbE ports and sockets
When the Decoder module is installed in the ProView 7000 device the module provides a
wide range of physical video and audio interfaces. All interfaces are displayed under the
Decoder card branch.
Right-click the device icon or any of the sub-elements in the Physical Output box to display a
context menu which includes the following items:
Table 4–13: TS Port Output Port Context Menu
Command Description
Disable/ Enable
A dynamic command, changing according to the operational status of the
TS Output Port.
Remove Selected
Removes the selected element.
Remove All Displays the following sub-menu items:
■ Remove All Output Programs on Port
■ Remove All Output Programs on Device
■ Remove All Output Unreferenced PIDs on Port
Refresh Transport Stream
Port Route
Updates the EMS screen. For details, see 4.7 Refreshing the EMS
Screen.
Properties
Displays the marked element properties dialog. For details, see
4.5.4 Multiplex & Decoding Output Properties.
Table 4–14: Device Icon Context Menu
Command Description
Refresh
Updates the EMS screen. For details, see 4.7 Refreshing the EMS
Screen.
Properties
Displays the marked element properties dialog for the marked element.
For details, see 4.5.5 Physical Output Interface Properties.
NOTE: No properties are available for the decoder output interfaces.
