Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 151 ProView 7000 v.2.4, Rev. A
DVB-S2 Reception Configuration Menu
The Reception Configuration menu provides the following options:
■ Universal/Wide Universal/K
u
/C Band Frequency (DVB-S and DVB-S2) – Sets the receiving
frequency according to the satellite LNB transmitting frequency. The receiver controls the
LNB band by sending a 22 kHz signal. When the signal is sent, the LNB uses its High Band
Local Oscillator (L.O.). When the signal is not sent, the LNB uses its Low Band L.O.
Two local oscillators exist, Universal and Universal Wide one for each band to leverage full
spectrum.
Configuration
Universal Band Frequency
10817000[kHz]
L Band Frequency
1067000[kHz]
Symbol Rate
27500000[baud]
Modulator Standard
DVB-S2
MODCOD
8PSK 2/3
Roll Off
35%
Pilot
On
Spectral Inversion
Inverted
Frame Size
Normal
Scrambling Seed
000000
Polarization
Vertical(13V)
Acquisition Mode
Wide Search
Drift Compensation
On
LNB Frequency Band
Universal (9.75, ...)
LO Frequency 9.750000 [GHz]
22 kHz Tone
Low Band (Off)
Draft Compensation
Off
Attenuation
00.0 dB
Gain
On
To Next Page
