Chapter 5 Front Panel Interface Front Panel Root Menu
© 2011 Harmonic Inc. 155 ProView 7000 v.2.4, Rev. A
5.2.1.2 Reception Status Menu
The Reception Status Menu displays the ProView 7000 Reception status.
❖ Navigate Root > Reception > Status.
The reception status is displayed whether the physical port is connected or not connected to
the DVB Multiplex In.
The Reception Status menu displays the following information:
NOTE: Some of the parameters apply to DVB-S or DVB-S2 modes only. They are displayed according to
the mode used.
■ C/N – displays the measured carrier to noise ratio [dBc]
■ Eb/N0 – displays the measured energy per bit to noise power spectral density ratio [dB]
■ Link Margin – displays the measured link margin level [dB]
■ BER – DVB-S only. Display the bit error rate detected
■ PER Value – DVB-S2 only. Display the packet error rate detected
NOTE: The BER/PER error rate is given in decimal number x 10-X (i.e., a.b E-X)
■ Carrier Locked – displays the carrier locking status: Locked (Yes) / Unlocked (No)
■ Demodulator Locked – displays the demodulator locking status: Locked (Yes) / Unlocked
(No)
■ Tuned Frequency – displays the reception tuned frequency [MHz]
■ Frequency Offset – displays the reception frequency offset from configured frequency
[MHz]
Status
C/N 24.100000[dBc]
Eb/N0 21.130000[dB]
Link Margin 17.400000[dB]
BER 1.2E-7
Carrier Locked Yes
Demodulator Locked No
Tuned Frequency 1067000[kHz]
Frequency Offset -955[kHz]
Spectral Inversion Normal
Modulation 8PSK
FEC Rate 2/3
