Appendix B Ports and Connectors Overview of Rear Panel Ports and Connectors
© 2011 Harmonic Inc. 183 ProView 7000 v.2.4, Rev. A
HD/SD-SDI 2 x HD/SD-SDI with embedded audio BNC, 75 Ω
AES/EBU 2 x AES/EBU digital audio output BNC, 75 Ω
HDMI HD monitoring interface, Audio 1 (stereo) embedded HDMI
Accessory and Management Interfaces
Management External access to the device for control and
monitoring
RJ-45
Control RS-232 interface connector D-Type, 9 pin
GPI General Purpose Interface connector, provides two dry
contacts to drive external alarm
(not supported in current release)
D-Type, 9 pin
AC Power Socket and
Switch
100–240 VAC 50/60Hz external power supply
connector (for 18AWG three wire cord) and ON/OFF
power switch
Grounding Jackscrew Jackscrew for connecting the grounding cable when
the unit is rack mounted
1. The number of RF satellite inputs depends on your hardware configuration.
Table B–1: Rear Panel Ports and Connectors
Interface Description Connector Type
