Installation
Input - Setting before shipment
Mark Description Default settings Available input codes Terminals 
I1 Input 1
i - 08
(Demand ON/OFF 1)
i - 00~17
(Except i - 07/12)
I1, L1
on TB3
Closed/Open
220-240V ~ 50/60Hz
I2 Input 2
i - 13
(Cycle 1 and 2 ECO mode)
i - 00~17
(Except i - 07/12)
I2, +12V
on TB4
Closed/Open 12V DC
I3 Input 3
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I3, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I4 Input 4
i - 04
(Solar in)
i - 00~17
(Except i - 07/12)
I4, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I5 Input 5
i - 02
(Smart Act.)
i - 00~17
(Except i - 07/12)
I5, +12V
on TB4
Closed/Open 12V DC
I6 Input 6
i - 06
(DHW Boost)
i - 00~17
(Except i - 07/12)
I6, L3
on TB3
Closed/Open
220-240V ~ 50/60Hz
I7 Input 7
i - 07
(Power meter 1)
i - 00~17
I7, COM
on TB4
Closed/Open 12V DC
I8 Input 8
i - 12
(Power meter 2)
i - 00~17
I8, COM
on TB4
Closed/Open 12V DC
I9 Input 9
i - 09
(Demand ON/OFF 2)
i - 00~17
(Except i - 07/12)
I9, +12V
on TB4
Closed/Open 12V DC
I10 Input 10
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I10, +12V
on TB4
Closed/Open 12V DC
I11 Input 11
i - 00
(No function)
i - 00~17
(Except i - 07/12)
I11, +12V
on TB4
Closed/Open 12V DC

the same time.
