Hisense AHM-080HCDSAA - Removing the Refrigerant Components; Removing the Low Pressure Switch (PSL)

444
Hi-Therma Monobloc System (AHZ-044/080HCDS1)
Fan motor
2.4.5 Removing the Refrigerant Components
2.4.5.1
Removing the Low Pressure Switch (PSL)
 Remove the Upper cover, as explained in “2.3.1.1 Removing the Upper cover”
 Remove the service cover, as explained in “2.3.1.2 Removing the Service cover”
 Remove the electrical box cover, as explained in “2.3.1.3 Removing the Electrical box cover”
 Remove the front cover, as explained in “2.3.1.4 Removing the Front cover”
Then,
1. Collect the refrigerant from the check joint.
2. Disconnect the PCN13 connector from the O.U. main PCB.
3. Remove the Low pressure switch with a blow torch.
Brazing
Low pressure switch
