General data
2. General data
2.1 Key Parameter
2.1.1 Hi-Therma Split
The heating capacity tables show the capacity and performance data in integrated values.
● The heating and cooling capacities are based on the EN 14511 standard:
Piping length: 7.5 meters; Piping lift: 0 meters.
● The noise values are measured in the anechoic chamber without reected echo, therefore the impact of the reected
echo must be taken into consideration at the scene, in accordance with the standard EN12102.
Measurement point
:
Outdoor unit,1m from the service cover surface and 0.88m from oor level.
Indoor unit,1m from the service cover surface and 1.5m from oor level.
Keywords:
● COP: Coe󰀩cient of performance
● EER: Energy e󰀩ciency ratio
● DB: Dry bulb(°C); WB: Wet bulb (°C)
OAT: Outdoor ambient temperature
IWT: Inlet water temperature
OWT: Outlet water temperature
Model 44(2.0 HP) 60(2.5 HP) 80(3.0 HP)
Outdoor Unit Type AHW-044HCDS1 AHW-060HCDS1 AHW-080HCDS1
Power Supply 220-240V~50Hz
Heating Operation
OAT (DB/WB) IWT / OWT - Unit Heating operation
7 / 6°C
30 / 35°C
Capacity
(Min./Nom./Max.)
kW 1.85 / 4.40 /7.00 1.95 / 6.00 /8.90 2.10/ 8.00 / 11.0
COP (Nom.) - 5.10 5.00 4.90
47 / 55°C
Capacity
(Nom./Max.)
kW 4.40 / 6.00 6.00 / 7.50 8.00 / 9.00
COP (Nom.) - 3.00 3.05 2.80
-7 / -8°C
30 / 35°C
Capacity
(Nom./Max.)
kW 4.40 / 5.00 5.30 / 5.90 5.80 /7.30
COP (Nom.) - 3.26 3.16 3.14
47 / 55°C
Capacity
(Nom./Max.)
kW 4.00 / 4.20 4.70 / 5.10 5.00 / 6.40
COP (Nom.) - 1.97 2.04 1.94
Cooling Operation 35 / --°C
12 / 7 °C
Nominal Capacity kW 4.40 5.00 6.00
EER - 3.90 3.70 3.60
23 / 18 °C
Nominal Capacity kW 5.60 6.00 7.00
EER - 5.60 5.60 5.10
Sound data*1
Normal Mode
(Heating/Cooling)
Sound Pressure dB(A) 47/47 48/47 50/47
Sound Power dB(A) 61/61 62/61 64/61
Quiet Mode
(Heating/Cooling)
Sound Pressure dB(A) 39/39 42/42 43/43
Sound Power dB(A) 54/54 56/56 57/57
Night shift Mode
(Heating/Cooling)
Sound Pressure dB(A) 35/35 38/38 39/39
Sound Power dB(A) 50/50 51/51 53/53
Outer Dimensions
Height mm 750 750 750
Width mm 900 900 900
Depth mm 340 340 340
Packing
Dimensions
Height mm 807 807 807
Width mm 1022 1022 1022
Depth mm 445 445 445
Net Weight kg 49.5 49.5 50.5
Gross Weight kg 53.5 53.5 54.5
Refrigerating
Installation
Compressor
Type - Rotary
Quantity - 1 1 1
Refrigeration
Oil
Type - ACS-68R ACS-68R FW68S
Charge L 0.47 0.47 0.46
Refrigeration
Charge
Type - R32
Before Shipment kg 1.23 1.23 1.26
Refrigerent Flow Control - Micro-computer Control Expansion Valve
Heat Exchanger Type - Multi-way Cross-ow Finned Tube Type
Gas Pipe (Piping diameter)
mm Ø12.7 Ø12.7 Ø15.88
in. 1/2
"
1/2
"
5/8
"
Liquid Pipe (Piping diameter)
mm Ø6.35 Ø6.35 Ø6.35
in. 1/4
"
1/4
"
1/4
"
Gas Pipe (Between IU and OU)
mm Ø12.7 Ø12.7 Ø15.88
in. 1/2
"
1/2
"
5/8
"
Liquid Pipe (Between IU and OU) *2
mm Ø6.35 (Ø9.53) Ø6.35 (Ø9.53) Ø6.35 (Ø9.53)
in. 1/4
"
(3/8) 1/4
"
(3/8) 1/4
"
(3/8)
