14
General data
2.4 Component data
2.4.1 Hi-Therma Split
Outdoor unit
Model 44(2.0HP) 60(2.5HP) 80(3.0HP)
Heat Exchanger
Heat exchanger Type - Multi-way cross-ow nned tube type
Tube
Material - Copper
Outer diameter mm 7
Rows - 2
Number of tubes in the heat exchanger - 44
Fin
Material - Aluminum
Pitch mm 1.40
Max. operating pressure MPa 4.15
Max. frontal area m
2
0.68
Number of heat exchanger per unit - 1
Fan Part
Fan
Type - Axial ow fan
Quantity - 1
Outer diameter mm 556
Rotating speed rpm 900 900
Fan Motor
Model - ZWB278D04A ZWB278D04A ZWB278D04A
Type - Waterproof brushless DC motor
Start-up mode - Soft driving
Nominal output
power
W 100
Quantity - 1
Insulation grade - E
Degree of Protection - IP24 IP24 IP24
Compressor
Part
Design pressure
High Side MPa 4.15 4.15 4.15
Low Side MPa 2.21 2.21 2.21
Compressor Motor
Model - WHP06840GUKQA8JT6 WHP06840GUKQA8JT6 SVB200FCNMC-L
Start-up mode - VFD VFD VFD
Polarities - 6 6 6
Quantity - 1 1 1
Insulation grade - E E E
Refrigerator Oil
Brand - ACS68R ACS68R FW68S
Volume L 0.47 0.47 0.46
