Hi-Therma Split system - Indoor unit (AHM-044/060/080HCDSAA)
2.2.6.3
Removing the Water Pump
Step 1: loosen two nuts in counter clockwise direction with
tools, remove the retaining plate and upper foam parts.
Step 2: loosen the two nuts counter clockwise to separate the
water pipe from the water pump and the water pump.
Step 3: the position indicated is the plug-in place of the
water pump power supply line and signal line, and the
pluggable terminal is used to remove the power supply
line and signal line.
Gasket
Gasket
Step 4: Install the water pump and operate in the reverse direction.
Pay attention to the installation of gasket during disassembly and assembly, otherwise the pipe may leak.
The pump is heavy to prevent injury from falling.
Pay attention to the protection of the removed pipeline. If foreign matters enter, the pipeline will be blocked.
