Hisense AHM-080HCDSAA - Hi-Therma Integra

6
General data
2.1.2 Hi-Therma Integra
The heating capacity tables show the capacity and performance data in integrated values.
● The heating and cooling capacities are based on the EN 14511 standard:
Piping length: 7.5 meters; Piping lift: 0 meters.
● The noise values are measured in the anechoic chamber without reected echo, therefore the impact of the reected
echo must be taken into consideration at the scene
,
in accordance with the standard EN12102.
Measurement point: 1m from the service cover surface and 0.9m from oor level.
Keywords:
● COP: Coe󰀩cient of performance
● EER: Energy e󰀩ciency ratio
● DB: Dry bulb(°C); WB: Wet bulb (°C)
OAT: Outdoor ambient temperature
IWT: Inlet water temperature
OWT: Outlet water temperature
Model 44 (2.0 HP) 60 (2.5 HP) 80 (3.0 HP)
Indoor Unit Type AHS-044HCDSAA-23 AHS-060HCDSAA-23 AHS-080HCDSAA-23
Power Supply 220-240V ~ 50Hz
Nominal water ow IWT: 30 ºC / OWT: 35 ºC ΔT: 5 ºC m
3
/h 0.76 1.03 1.38
Outer Dimensions
(with connections)
Height mm 1885 1885 1885
Width mm 595 595 595
Depth mm 625 625 625
Packing Dimensions Height mm 2070 2070 2070
Width mm 700 700 700
Depth mm 710 710 710
Net Weight kg 124.5 124.5 125.0
Gross Weight kg 145.0 145.0 145.5
Refrigerating
Installation
Connection type - Flare nut connection
Liquid pipe (Piping diameter) mm Ø6.35 Ø6.35 Ø6.35
in. 1/4" 1/4" 1/4"
Gas pipe
（
Piping diameter) mm Ø12.7 Ø12.7 Ø15.88
in. 1/2" 1/2" 5/8"
Space heating pipes
connection
Connection type - Screwed connection
Shutdown valves in. G 1” (male) - G 1” (male)
Inlet pipe diameter in. G 1" (female)
Outlet pipe diameter in. G 1" (female)
DHW pipes
connection
Connection type - Screwed connection
Inlet pipe diameter in. G 3/4" (female)
Outlet pipe diameter in. G 3/4" (female)
DHW tank rated volume L 230
Noise level (sound pressure)*1 dB(A) 26 26 26
Noise level (sound power) dB(A) 42 42 42
Note
* 1. The above noise values are measured in the anechoic chamber without reected echo, therefore the impact of the
reected echo must be taken into consideration at the scene.
* 2. The ambient temperature of the outdoor unit shall be ≥10°C, and the refrigerant charge of the unit shall be less than the
maximum refrigerant charge allowed by the unit.
* 3. With the factory-supplied DHW electric heater in the DHW tank, the setting temperature can reach 75°C.
For the outdoor unit capacity table of Hi-Therma Integra, please refer to 2.1.1 Hi-Therma Split outdoor unit type.
