Hisense AHM-080HCDSAA - Page 26

5
General data
Fan
Condenser Fan Quantity —— 1 1 1
Air Flow Rate m
3
/h 2700 2700 2700
Minimum piping length m 5
Maximum chargeless piping length m 15
Maximum piping length m 40 40 45(50*3)
Height di󰀨erence between OU and IU (higher OU / lower OU) m 30 / 20
Working range
(Space Heating)
Outdoor ambient temperature °C (DB) -25~35
Outlet water temperature °C 15~60
Working range
(Space Cooling)
Outdoor ambient temperature °C (DB) 5~46
Outlet water temperature °C 5~22
Working range
(DHW)
Outdoor ambient temperature °C (DB) -25~40
Tank water temperature °C 30~55(75*4)
Working range
(SWP)
Outdoor ambient temperature °C (DB) -25~40
Swimming pool water temperature °C 24~33
Model 44(2.0 HP) 60(2.5 HP) 80(3.0 HP)
Indoor Unit Type AHM-044HCDSAA AHM-060HCDSAA AHM-080HCDSAA
Power Supply 220-240V~50Hz
Nominal water ow IWT: 30 °C / OWT: 35 °C ΔT: 5 °C m
3
/h 0.76 1.03 1.38
Outer Dimensions
(with connections)
Height mm 890 890 890
Width mm 520 520 520
Depth mm 320 320 320
Packing Dimensions
Height mm 419 419 419
Width mm 1160 1160 1160
Depth mm 650 650 650
Net Weight kg 41.5 41.5 42.5
Gross Weight kg 48.5 48.5 49.5
Refrigerating
Installation
Connection type - Flare nut connection
Liquid pipe (Piping diameter)
mm Ø6.35
in. 1/4"
Gas pipe (Piping diameter)
mm Ø12.7 Ø12.7 Ø15.88
in. 1/2" 1/2" 5/8"
Space heating pipes
connection
Connection type - Screwed connection
Shutdown valves mm (in.) G 1" (male) - G 1" (male)
Inlet pipe diameter mm (in.) G 1" (female)
Outlet pipe diameter mm (in.) G 1" (female)
Noise level (sound pressure)*1 dB(A) 28 28 28
Noise level (sound power) dB(A) 42 42 42
Note
* 1. The above noise values are measured in the anechoic chamber without reected echo, therefore the impact of the
reected echo must be taken into consideration at the scene.
* 2. The ambient temperature of the outdoor unit shall be ≥10°C, and the refrigerant charge of the unit shall be less than the
maximum refrigerant charge allowed by the unit.
* 3. When there is a DHW electric heater mounted in the DHW tank, the setting temperature can reach 75°C.
