Installation
8.1.4.2
FACTORY-SUPPLIED INDOOR UNIT
COMPONENTS
Accessory Image Qty. Remarks
Wall support 1
For hanging the unit on the
wall
Gasket 6
Six gaskets for each
connections between the
valves (inlet/outlet)
(G1”)
1
Connect at the water inlet/
outlet of indoor unit, used
1
Connect at the water inlet/
outlet of indoor unit, used
water.
Cable tie 3 Used for wiring binding.
Drain pipe
clamp
1
Used for fastening drain
hose and drain pipe.
Drain pipe
clamp
1
Used for fastening drain
hose and drain pipe.
Drain pipe 1
Used for drain hose
connection
Bolts 2
the wall support
Instruction
manual
1
Basic instructions for the
installation of the device.
NOTE
The previous accessories are supplied inside the packing
assembly (besides the indoor unit).
outdoor unit needs to be available.
If some of these accessories are not packed with the unit or
any damage to the unit is detected, please contact your dealer.
