Hisense AHM-080HCDSAA - Removing the 4-Way Reversing Valve Coil

446
Hi-Therma Monobloc System (AHZ-044/080HCDS1)
Grooves
Fixation protrusion
The electronic expansion valve will malfunction if the coil does not x rmly with the valve body by the groove and the xation
protrusion.

4. 
Brazing
2.4.5.4
Removing the 4-way Reversing Valve Coil
 Remove the Upper cover as explained in “2.3.1.1 Removing the Upper cover”
 Remove the service cover, as explained in “2.3.1.2 Removing the Service cover”
 Remove the electrical box cover, as explained in “2.3.1.3 Removing the electrical box cover”
 Remove the Front cover, as explained in “2.3.1.4 Removing the Front cover”
Then,
1. 
2. Disconnect the PCN6 connector on the O.U. main PCB of the electrical box.
3. Remove the cable from the clamps.
4. 
4-
Screw
