440
Hi-Therma Monobloc System (AHZ-044/080HCDS1)
2. Pull the service cover in the direction shown by the arrow and remove it
2. Pull the electrical box cover in the direction shown by the arrow and remove it.
2.4.1.3
Removing the Electrical Box Cover on the Indoor Part
Remove the service cover as explained in “2.3.1.2 Removing the Service cover”
Then,
1. 
Electrical box cover
Electrical box cover
