General data
2.5 Safety and control Device
Compressor protection
The compressor is protected by the following devices and their combinations.
(1) High pressure switch: This switch cuts out the operation of the compressor when the discharge pressure exceeds the
setting.
(2) Low pressure switch: This switch cuts out the operation of the compressor when the suction pressure exceeds the
setting.
Fan motor protection
When the thermistor temperature is reached to the setting, motor output is decreased. The other way, when the temperature
becomes lower, limitation is canceled.
2.5.1 Hi-Therma Split
Outdoor unit
MODEL 044(2.0HP)/060(2.5HP)/080(3.0HP)
For compressor
Pressure switches Automatic reset, non-adjustable
High
Cut-out
MPa
4.4±0.15
Cut-in 3.40±0.2
Low
Cut-out
MPa
0.05±0.03
Cut-in 0.15±0.03
Fuse capacity on PCB1 (PF1) 220-240V ~ 50Hz A 30
CCP timer - Non adjustable
Setting time min. 3
For condenser
fan motor
Internal Thermostat - Automatic Reset, Non-Adjustable
Indoor unit
MODEL 044(2.0HP)/060(2.5HP)/080(3.0HP)
For Auxiliary electric heaters
Automatic Reset Thermostat °C Cut-out: 75°C±4°C
Temperature fuse °C 94°C
+0
°C
-10
Fuse capacity 220-240V ~ 50Hz A 20
For water circulation
Low water pressure protection Condition 1 Pw<0.3Bar for 180 seconds
High water pressure protection Condition 2 Pw>4.0Bar for 180 seconds
Minimum water ow rate m
3
/h 0.5(044)/0.6(060-080)
Water pump control - Water Pump status by feedback control
For the control circuit Fuse capacity 220-240V ~ 50Hz A 10 (Inside PCB1,EFR1)
For DHW Electric Heater Fuse capacity 220-240V ~ 50Hz A 20
2.5.2 Hi-Therma Integra
For outdoor unit safety and control device parameters, please refer to 2.5.1 Hi-Therma Split outdoor unit.
Indoor unit
MODEL 044(2.0HP)/060(2.5HP)/080(3.0HP)
Auxiliary electric
heater
Automatic Reset Thermostat °C Cut-out: 75°C±4°C
Temperature fuse °C 94°C
+0
°C
-10
Fuse capacity 220-240V ~ 50Hz A 20
Water circulation
Low water pressure protection
Condition
1
Pw<0.3Bar for 180 seconds
High water pressure protection
Condition
2
Pw>4.0Bar for 180 seconds
Minimum water ow rate m
3
/h 0.5(044)/0.6(060-080)
Water pump control - Water Pump status by feedback control
Safety valve bar 3
Control circuit Fuse capacity 220-240V ~ 50Hz A 10 (Inside PCB1, EFR1)
DHW Electric Heater
Fuse capacity 220-240V ~ 50Hz A 20
Mechanical thermostat °C Cut-out: 85ºC±5ºC, manual reset
DHW Tank Pressure relief valve bar 7±0.5
