Installation
8.3.11 MAIN SAFETY DEVICES
◆
Compressor protection
High pressure switch:
This switch cuts out the operation of the compressor when
the discharge pressure exceeds the setting.
◆
Fan motor protection
When the thermistor temperature is reached to the setting,
motor output is decreased.
Otherwise, when the temperature becomes lower, limitation
is cancelled.
Capacity 44(2.0HP) 60(2.5HP) 80(3.0HP)
For compressor
Pressure switches - Automatic Reset, Non-Adjustable
High Cut Out MPa 4.4±0.15
Cut-In MPa 3.4±0.2
Low Cut Out MPa 0.05±0.03
Cut-In MPa 0.15±0.03
Fuse on Main Circuit
A 30
220-240V ~ 50Hz
CCP Timer - Non-Adjustable
Setting Time min. 3
For condenser fan motor
- Automatic Reset, Non-Adjustable
Internal Thermostat
