Hisense AHM-080HCDSAA - Removing the PCB4; Removing the PCB5

417
Hi-Therma Split system - Indoor unit (AHM-044/060/080HCDSAA)
2.2.7.3
Removing the PCB4
To Remove the PCB4, the following operations should be done:
 Remove the front cover, as explained in “2.2.1 Removing the front cover”
1. Remove all the connectors connected to the PCB4.
2. 
2.2.7.4
Removing the PCB5
To Remove the PCB5, the following operations should be done:
 Remove the front cover, as explained in “2.2.1 Removing the front cover”
1. Remove all the connectors connected to the PCB5.
2. 
Plastic holders (x6)
Plastic holders
Plastic holders
3. Remove the PCB4. If necessary, replace the PCB4 with a new
one proceeding in reverse way than disassembling.
3. Remove the PCB5. If necessary, replace the PCB5 with a new
one proceeding in reverse way than disassembling.
Plastic holders
Plastic holders
Plastic holders (x8)
